VIGIL3 PAVA System

Public Address & Voice Alarm Systems

VIGIL3 is our latest Voice Alarm system providing the assurance of top quality British manufacturing along with a system that we have designed with a vision of future-proofing our technologies for many years to come.

Meaningful, user-friendly, safe and compliant, Baldwin Boxall’s VIGIL3 system is built with the latest features, such as user-configurable touchscreen control, and site-wide configuration from a single point.

Built on decades of experience, VIGIL3 is our most flexible, scalable and powerful system to date. With up to 400 inputs and 800 outputs possible on a single system, VIGIL3 is an investment for the future.

Configuring a VIGIL3 system, no matter the size, whether centralised or de-centralised, can be done from a single point. This means any adjustments can be done without the hassle of walking long distances between different points of the system to repeat changes. An engineer can simply make the changes, such as the uploading of new messages or any other configuration requirement at the closest, or most accessible point, saving valuable time.

Browse Products

Make an Enquiry

Further Information

Fault-tolerant Ethernet backbone
VIGIL3 is entirely modular – systems can grow according to a user’s needs.
400 inputs and 800 outputs possible on a single system
Suitable for single, centralised and de-centralised systems
Single point for configuration/message upload/fault log access
Truly distributed but forming a single voice alarm system
Can be realised as both rack and wall mounted (Eclipse5) systems
No Ethernet switches required
Up to 24 band parametric EQ on outputs
No software licence payments – ever
All connections monitored for reliability and peace of mind
Mix & match copper and fibre network interfaces
Fast and responsive – even on very large systems

Product Range

BV300D / BV150D / BV075D
Amplifier – transformerless
Dual 300W / Dual 150W / Dual 75W
142mm x 75mm x 311mm
3.1 kg / 2.3 kg / 2.3 kg

BV150Q / BV075Q
Amplifier – transformerless
Quad 150W / Quad 75W
142mm x 75mm x 311mm
3.1 kg / 3.1 kg

BV3MF
Amplifier mainframe
Holds up to 3 VIGIL3 amplifiers

BV3AOM8
Audio output module
75mm x 71mm x 311mm
1.1 kg

BV3AIM2 / BV3AIM4
Audio input module
2 inputs / 4 inputs
DIN rail mounted
111mm x 129mm x 55mm / 111mm x 129mm x 75mm
0.36 kg / 0.4 kg

BVMBC
Battery charger/monitor module
75mm x 71mm x 311mm
1.1 kg

BV3FPI
Fire panel interface

BV3BYP
Processor hard-wired bypass interface

BVRDCI
Universal zonal access switching interface

BVRDCIMON
VACIE/CIE interface monitor

BV3MDP10F / BV3MDP05F
Mains distribution w. fans
10-way / 5-way

BV3MDPEFM
Exhaust fan module

BV3EFM
Exhaust fans & cooling control for
up to 3 amplifiers

BV3CIF / BV3FIFM / BV3FIFS
Networking interface
Copper / multi-mode fibre / single-mode fibre

Safe & Compliant

BS EN 54: Fire Detection & Fire Alarm Systems, is a mandatory standard that specifies requirements and laboratory testing for every component of fire detection and fire alarm system.

UKCA (UK Conformity Assessed) marking on products replaces CE marking in the UK and requires that certification of construction products, such as VACIE / Voice Alarm Control & Indicating Equipment is performed by a UK-based approved body.

BS 5839-8 is a BSI Standards Publication code of practice providing recommendations for the design, installation, commissioning, and maintenance of voice alarm systems that automatically broadcast speech or warning tones, in response to signals from their associated fire detection and fire alarm systems.

Key Benefits

Our aim is to shape a greener future

for a more environmentally friendly world

VIGIL3 PAVA System

Fast. Powerful. Flexible. VIGIL3 is built with a fault-tolerant ethernet backbone, no ethernet switches are required and there are no licence fees. From a single rack to large distributed systems with hundreds of outputs, use wall mount or rack mount for outputs in any combination.
