Key Benefits
Flexible System Growth
- Supports up to 32 outstations and 32 assistance alarms as standard
- One line card fitted as standard
- Up to three additional line cards can be fitted
- With four cards installed:
- Up to four loops with a maximum of 32 outstations spread across the loops in any combination or
- Up to 16 radial circuits
-
Or a mix of loop and radial circuits in any configuration up to a maximum of 32 outstations
Networked System Design
- Up to 100 OmniCALL panels on one system
- Typical system capacity of 512 outstations and 512 assistance alarms
- Larger capacities available on request
- Built-in copper networking using 4-core FP200 cabling up to 200 metres per span
- Optional fibre modules:
- Single mode up to 4km
- Multi mode up to 2km
Built-in Resilience
- Internal batteries sized to project requirements
- Fully monitored system operation
- Two-core non-polarity-dependent wiring
OCEPS delivers structured, scalable system expansion without adding unnecessary complexity.
